Bettis TorqPlus Electric Valve Actuator

Name: Bettis TorqPlus Electric Valve Actuator
Brand: Bettis

The Bettis TorqPlus Electric Actuator employs a unique modular design to allow for simple retrofits using over 200 different accessory kits.

Specs

Actuation

Electric

Certifications

CSA, NEMA

Control Type

On/off, Positioning, Throttling

Power Source

Electric

Product Type

Electric Actuator

Torque/Thrust

Quarter-turn torque: 11 Nm (8 ft lbs) to 2,260 Nm (1,667 ft lbs)

Valve Type

Ball, Butterfly, Plug, Choke

Five models with output torques ranging from 100 in-lbs-in to 20,000 in-lbs-in (11 Nm to 2,260Nm)
Standard for torques as low as 350 lbs-in through 10,000 lbs-in torques is 100% (none less than 50% in all available motor voltages)
Compact design in weatherproof and explosion-proof housings
Modular design readily accommodates controls and accessories such as heaters, motor brakes, positioners, transmitters and control stations
Permanent lubrication reduces the need for scheduled maintenance
High strength gearing run in needle bearings for smooth energy transfer and long service life
Engineered for Open/Close, Continuous Duty Cycle and Modulation application.
Mechanical driven fail-safe operation (Fail Clockwise or Counter-Clockwise)
